Razor DII & RII Front-to-Back Tarp System

The Razor DII‑RII Front‑to‑Back Tarp System provides a safe, reliable, and efficient way to cover semi-trailers and rigid trucks — all designed to keep the driver inside the cab and out of harm’s way.

Choose from one of four kit configurations (listed below) to receive a complete system including: motor + gearbox, controller, wireless remote, mounting hardware, and emergency manual override.

Features:
• Australian-designed and tested
• Wireless operation via remote or in-cab control
• Razor Connect compatible with tarp-wear monitoring
• Solid-aluminium, fully sealed casing
• Modular and fully serviceable parts
• Built-in emergency manual override

WorkSafe & Safety Benefits:
• Reduces manual handling and risk of injury
• Modular quick-separate design
• Saves time and improves productivity
• 12-month warranty & low-maintenance design
• Prevents back strain and exposure to weather

Specifications:
• Weight: 5.5 kg (no battery), 13 kg (with battery)
• Voltage: 12 V DC (10.5–30 V operating range)
• Operating Temp: –30 °C to +60 °C
• Weather Rating: IP65 (with isolator)
• Torque: 120 Nm
• Cycle Time: ~20 seconds

Kit Options Overview:

What’s Included:
• Motor + Gearbox Unit
• Internal or External Controller (based on kit)
• Wireless Remote + Cabling
• Mounting Hardware + Brackets
• Emergency Manual Override
• Razor Power Kit (Battery Support)
• Full Installation Instructions

Technical Downloads:
• Razor DII HRPT Wiring Schematic
• Razor DII PVC Wiring Schematic
• Razor RII HRPT Wiring Schematic
• Razor RII PVC Wiring Schematic
• INCAB VERSION – Razor DII HRPT Wiring Schematic
• Razor RII Product Manual
• Razor DII/D1.5 Product Manual
• Razor DII Parts Breakdown
• Razor RII Parts Breakdown

Shipping & Support:
• Ships within 1–2 business days from NSW
• Genuine Razor International product
• Warranty and support provided directly by Razor
