Razor DII/RII Rollover Tarp System – Complete Kit

Razor DII/RII Rollover Tarp System – Complete Kit
Premium electric rollover tarp system that lets the driver operate from the cab, cuts manual handling, and adds serious safety and speed. Includes manual override and a battery Power Kit for reliable operation. We’ll contact you after checkout to confirm the correct specialised option for your vehicle.

Why Choose Razor Rollover

• Operate from the cab; faster turnarounds & improved safety
• Manual override + battery Power Kit for backup use
• Touch-pad control with adjustable sensitivity (smooth open/close)
• Robust, low-maintenance components built for harsh conditions

What’s Included (Complete Kit)

• Razor motor/gearbox assembly
• Controller (internal or external type, per system)
• Wireless remote & cab control pad
• Battery Power Kit with trickle charge
• Arms/brackets & mounting hardware
• Manual override capability

Base System Options (we supply the correct one)

• DII-7R23 — Delta II, internal controller
• RII-ROLL23 — RII, external controller

6 Specialised Variants (same price)

Chosen during our post-purchase confirmation call:

• DII-7R23-R — Internal controller, reverse mount
• DII-7R23-S — Internal controller, shorter length
• DII-7R23-SR — Internal controller, reverse mount, shorter length
• RII-ROLL23-R — External controller, reverse mount
• RII-ROLL23-S — External controller, shorter length
• RII-ROLL23-SR — External controller, reverse mount, shorter length

Fitment & Use

• Semi-trailers & rigids needing side-to-side tarp
• Quarry, civil, agriculture, bulk haulage

How Ordering Works

1. Checkout at the listed price (complete kit).
2. We contact you to confirm body length, mount orientation, controller type, and supply the correct specialised variant.
3. We ship the matched kit and arrange any support needed.

FAQs

Are the 6 specialised options different prices?
No — they’re the same price; we match the correct one after purchase.

What if I’m unsure about internal vs external controller?
No stress — we confirm it with photos/measurements after checkout.

Can I still operate it if the truck is off?
Yes — the Power Kit allows multiple operations before recharge, plus manual override.

Need help first? Call us and we’ll recommend the right setup from your photos and dimensions.

Razor DII/RII Rollover Tarp System

Technical Files

Razor DII Rollover Wiring Scematic

Razor RII Rollover Wiring Schematic

Product Manual - Razor RII Rollover Tarp Kit

Product Manual - Razor DII Rollover Tarp Kit

Razor DII Rollover System Parts Breakdown

Razor RII Rollover System Parts Breakdown

Rollover Standard Installation (DII-7R23, RII-ROLL23)

Rollover Standard Fitup Sheet (DII-7R23, RII-ROLL23)

Rollover Base Bracket Drill Template

Rollover Cable Anchor Drill Template

Rollover Standard Bracket Mount Fitup Sheet

Rollover Tarp Reverse Installation Instruction (DII-7R23-R, RII-ROLL23-R)

Rollover Installation (Short-Standard) (DII-7R23-S, RII-ROLL23-S)

Rollover Installation (Short-Reverse) (DII-7R23-SR, RII-ROLL23-SR)
